Cable Tray Straight Sections

Cable Tray Straight Sections

SKU KK-4X2X5-EZ

Login To View Discounted Pricing

$61.94 - $168.44
$61.94
$61.94 - $168.44
$61.94
Request a quote

Want to Sell Our Products. Click Here

  • 2, 4 & 6 inch Deep Tray Walls
  • UL Listed – File No. E352552 (On Selected Sizes Only)
  • Electro Zinc Resistant Finish Protects The Steel Wire Mesh Cable Trays From Weather & Chemical Corrosion
  • Suspends Cables, Out of The Way, in an Expandable & Versatile Fashion. Perfect for Network, Fiber Optic, Mineral Insulated & Metal Clad Cabling
  • Can Be Sized to Fit Your Needs With Cable Tray Cutters
  • It is Recommended That Installers Add Support Every Five Feet Increment

Kable Kontrol’s professional quality Steel Wire Mesh Cable Management Cable Trays for your building's wire management needs. Our standard and budget-friendly cable and wire tray system comes in four different widths (4", 6", 8", 12") at a 2" depth and 9.84' (3m) length with a wire thickness of 0.197". Steel Cable trays all have Electro Zinc resistant finish and are NEC Approved

ONLINE RETAILERS

Technical Specifications

Part # Color Length Width Height Cable Fill (50% Fill) UL
 Listed
Actual Area
Inside Tray (in²) 		Number of
CAT 5e Cables 		Number of
CAT 6 Cables 		Number of
CAT 6A Cables
KK-4X2X5-EZ Silver 5 FT 4” 2" 8.2 118 83 64 _
KK-4x2x10-EZ Silver 10 FT 4” 2" 8.2 118 83 64 _
KK-6X2X5-EZ Silver 5 FT 6” 2" 12.1 175 123 95 _
KK-6x2x10-EZ Silver 10 FT 6” 2" 12.1 175 123 95 _
KK-8X2X5-EZ Silver 5 FT 8” 2" 16.1 231 163 125 _
KK-8x2x10-EZ Silver 10 FT 8” 2" 16.1 231 163 125 _
KK-12X2X5-EZ Silver 5 FT 12” 2" 23.9 345 243 187 E352552
KK-12x2x10-EZ Silver 10 FT 12” 2" 23.9 345 243 187 E352552
KK-4X4X5-EZ Silver 5 FT 4" 4” 15.8 227 160 123 E352552
KK-6X4X5-EZ Silver 5 FT 6" 4” 23.6 341 240 185 E352552
KK-8X4X5-EZ Silver 5 FT 8" 4” 31.5 454 321 247 E352552
KK-12X4X5-EZ Silver 5 FT 12" 4” 47.5 686 484 372 E352552
KK-18X4X5-EZ Silver 5 FT 18" 4" 71.5 1032 728 560 E352552
KK-24X6X5-EZ Silver 5 FT 24" 6” 143.3 2068 1459 1123 E352552
